Radifocus™ Introducer II Transradial Kit M Coat™ R

Introducer Sheath

Description

Introducers are intended to be inserted percutaneously into a vessel to facilitate the entire interventional procedure.

Being a pioneer and a leader in vascular access, Terumo’s goal is to offer complete solutions for transradial interventions with devices that minimize patient stress and optimize outcomes.

Characteristics

Easy insertion and removal with proprietary Terumo M Coat™ hydrophilic
Total Integrated Fit (TIF) tip tapering: tapering design at the tip of the sheath and dilator to facilitate smooth penetration
Cross-cut hemostasis valve: to avoid blood reflux and air aspiration
Thin radiopaque sheath with anti-kinking sleeve: for easycatheter handling
Snap-on / click-off dilator lock: prevents dilator back-out during insertion and allows one-hand unlocking

General specifications

Sheath length	10 cm, 16 cm and 25 cm
Sheath coating	Hydrophilic M Coat™
Mini guidewire	Spring Straight 0.021" (0.53 mm) and 0.025" (0.64 mm) 45 cm for 10 cm sheath, 80 cm for 16 cm and 25 cm sheath
Entry needle	Metallic entry needle 21G x 1 2/5" (0.8 x 35 mm), 20G x 1 2/5" (0.9 x 35 mm)
Guidewire compatibility	0.021" (0.53 mm) and 0.025" (0.64 mm)
Packaging	Tray
Dilator internal tip diameter	Equals to mini guidewire external diameter
R Kit content	Sheath, dilator, spring mini guideiwre and metallic entry needle

Enlarge table

Item specifications

Inner diameter	Guidewire compatibility	Sheath length
Inner diameter	Guidewire compatibility	10 cm	16 cm	25 cm
5 Fr	0.021" (0.53 mm)	RM*RF5F10PQ	RM*RF5F16PQ	RM*RF5F25PQ
5 Fr	0.025" (0.64 mm)	RM*RF5J10PQ	RM*RF5J16PQ	RM*RF5J25PQ
6 Fr	0.021" (0.53 mm)	RM*RF6F10PQ	RM*RF6F16PQ	RM*RF6F25PQ
6 Fr	0.025" (0.64 mm)	RM*RF6J10PQ	RM*RF6J16PQ	RM*RF6J25PQ

Enlarge table

Please quote above item reference codes when placing an order
